Subscription Plans

Basic concept

Some things in a brezel system can be bought / unlocked with a paywall.

For that, there is the concept of “plans” which can be bought/activated via a subscription. These define prices and most importantly, “Features” that can be used to enable or disable things in the system.

Feature summary

A User entity with the “Billable” Capability can buy a plan for an Entity.
The User will be registered as a customer in stripe and charged for the selected plan by stripe.
Only entities from Modules that use the Buyable Capability can be bought. In the options of that capability, the subscription_plans which contain feature flags and prices are defined.
The Entity will then have the fields active_plans and active_features set, which can be used by workflows, policies, recipes etc. to enable or disable features.
To react on payment events, there are several workflow events that can be used to hook into.

Additional features to manage plans

Ability to build an overview that see all active plans
Ability to manually assign active plans to an entity
Log for payment activities
- “User A bought plan B for entity C for price D at time E”
- “Plan B was deactivated for entity C at time E”
- “Payment by User A for plan B for entity C failed at time E”
Ability to start a Stripe customer portal session for a user to manage their subscriptions

Use cases

Buy something for an Entity

A User can buy a plan on an Entity. The system could then enable or disable features for things concerning that Entity.

Examples:

Unlocking “premium” features for a website in KAB.page
- A user buys a “premium” plan for a website.
- The system enables the “premium” features for that website.
Unlocking “shop” features for a website in KAB.page
- A user buys a “shop” plan for a website.
- The system enables the “shop” features for that website.

Buy something for a Client

A User can buy a plan for a Client (which is just the same as any entity). The system can then enable or disable features for things concerning that Client. That could include all Users and Entities of that Client.

Examples:

Enabling client wide features
- The user buys the plan to use feature X for his client
- The system enables feature X for all Users and Entities of that Client.
  - e.g. allowing access to a new module / feature-set
SAAS style plans
- A user buys a “business” plan for a Client.
- The system enables the “business” features for that Client.
  - That allows X users to be created for that client
  - Enables X feature (e.g. DATEV export) for bills of that client
- The system disables the “business” features for all Users and Entities of that Client when the plan expires.
  - All users except the main user that bought the plan (hopefully the boss) are disabled and cannot log in anymore.
  - Or just disable the creation of any new entities for that client.

How to react to payment events?

There are several workflow events that can be used to react to payment events.

Some are to be used for feature management and day-to-day operations. These all return the Entity in question, the User entity that bought / tried to buy the plan, and the Plan itself.

event/planPaymentFailed: Fires when a payment for a plan failed for an entity of the specified module.
event/planActivated: Fires when a plan was activated for an entity of the specified module.
event/planDeactivated: Fires when a plan was deactivated (e.g. when a subscription runs out) for an entity of the specified module.

Some are to be used for plan management and just return the Plan in question.

event/planFeaturesChanged: Fires when the features of a plan were changed for the specified module.
event/planDeleted: Fires when an existing plan was deleted for the specified module.

Architecture overview

Buyable

Type definitions on module level:

type Plan = {
  id: string          // Unique identifier for that plan. Used as `lookup_key` for stripe product and as identifier to use when checking for features.
  name: string        // Human readable name of the plan and name of the product in stripe.
  features: Feature[] // Features of the plan. The same feature can be used in multiple plans.
  price: Price[]      // Prices of the plan.
}

type Feature = {
  identifier: string // Unique identifier for the feature. Can be used to enable or disable the feature in the system.
  name: string       // Human readable name of the feature.
}

type Price = {
  identifier: string       // Unique identifier for the price. Used as `lookup_key` for stripe price.
  price: number            // Price with 2 decimal places. E.g. 9.99
  currency: string         // Currency to use in stripe. E.g. "eur", "usd", "inr"
  interval: 'month'|'year' // Payment interval to be used for the subscription.
}

Fields present on an Entity that could have active plans:

type Entity = {
  active_plans: PurchasedPlan[] // Array of active plans for that entity.
  active_features: string[]     // Array of active features for that entity. This is derived from all features of all active plans.
  // ... All other fields of the entity, including id, module_id etc.
}

// Very similar to the Plan type used in the configuration, but has only one price (the one, that was chosen by the user to purchase the plan).
type PurchasedPlan = {
  id: string          // Unique identifier for that plan. Used as `lookup_key` for stripe product and as identifier to use when checking for features.
  name: string        // Human readable name of the plan and name of the product in stripe.
  features: Feature[] // Features of the plan.
  price: Price        // Price the plan was bought with.
}

Billable

Field requirements on entity that should be able to buy something:

[
  {
    "identifier": "name", // Name of the user to use in stripe
    "type": "text",
    options: {
      "rules": "required" // This is required for stripe taxes to work
    }
  },
  {
    "identifier": "email", // Email to register the user in stripe with
    "type": "email",
    options: {
      "rules": "required" // This is required for stripe taxes to work
    }
  },
  {
    "identifier": "country_code", // ISO 3166-1 alpha-2 country code of the user
    "type": "text",
    options: {
      "rules": "required" // This is required for stripe taxes to work
    }
  },
  {
    "identifier": "postal_code", // Postal code of the user
    "type": "text",
    options: {
      "rules": "required" // This is required for stripe taxes to work
    }
  }
]

Usage

Add the Billable capability to a User entity.
Define a module with the Buyable capability.
Configure the available subscription_plans in the options of that capability.
Make the user buy a plan for an entity somehow. (TODO)
Use the active_features fields on the entity to enable or disable features in your workflows, policies, recipes etc.

Example configuration of a user

This defines a user with the Billable capability.

It uses all the default fields (will create them in this case) except for the name field, which is mapped to the existing full_name field.

JSON Configuration for a user

{
  "resource_user": {
    "identifier": "user",
    "type": "user",
    "options": {
      "capabilities": [
        {
          "identifier": "Billable",
          "options": {
            "field_mapping": {
              "name": "full_name"
            }
          }
        }
      ]
    },
    "fields": [
      {
        "identifier": "full_name",
        "type": "text"
      }
    ]
  }
}

Example configuration of a module

This defines two plans with the same features payable either monthly and yearly either in $ or €.

Includes another “lite” plan with only one of the features.

Checking for features has to be done via permissions / policies / workflows using the fields on the Entity.

JSON Configuration for a module

{
  "resource_module": "buyable_thingy",
  "resource": {
    "identifier": "buyable_thingy",
    "type": "module",
    "options": {
      "capabilities": [
        {
          "identifier": "Buyable",
          "options": {
            "subscription_plans": [
              {
                "identifier": "pro_monthly",
                "name": "Pro subscription monthly",
                "description": "This gives you cool PRO features",
                "features": [
                  {
                    "identifier": "pro_feature_x",
                    "name": "Feature X"
                  },
                  {
                    "identifier": "pro_feature_y",
                    "name": "Feature Y"
                  }
                ],
                "prices": [
                  {
                    "identifier": "pro_monthly_usd",
                    "price": "21.00",
                    "currency": "usd",
                    "interval": "month"
                  },
                  {
                    "identifier": "pro_monthly_eur",
                    "price": "20.00",
                    "currency": "eur",
                    "interval": "month"
                  }
                ]
              },
              {
                "identifier": "pro_yearly",
                "name": "Pro subscription yearly",
                "description": "This gives you cool PRO features",
                "features": [
                  {
                    "identifier": "pro_feature_x",
                    "name": "Feature X"
                  },
                  {
                    "identifier": "pro_feature_y",
                    "name": "Feature Y"
                  }
                ],
                "prices": [
                  {
                    "identifier": "pro_yearly_usd",
                    "price": "180.00",
                    "currency": "usd",
                    "interval": "year"
                  },
                  {
                    "identifier": "pro_yearly_eur",
                    "price": "180.00",
                    "currency": "eur",
                    "interval": "year"
                  }
                ]
              },
              {
                "identifier": "lite",
                "name": "Lite subscription",
                "description": "Get a taste of some PRO features",
                "features": [
                  {
                    "identifier": "pro_feature_x",
                    "name": "Feature X"
                  }
                ],
                "prices": [
                  {
                    "identifier": "pro_monthly_usd",
                    "price": "16.00",
                    "currency": "usd",
                    "interval": "month"
                  },
                  {
                    "identifier": "pro_monthly_eur",
                    "price": "15.00",
                    "currency": "eur",
                    "interval": "month"
                  }
                ]
              }
            ]
          }
        }
      ]
    }
  }
}

Technical implementation details

Modules with the Buyable capability can be bought by users with the Billable capability.
The plans (products in stripe) and their prices defined in the Buyable Capability are automatically created and synced with Stripe at bakery apply time.
- Uses the identifier as lookup_key for the price in stripe as this is the “identifying information” we use when buying a plan
- The identifier of the plan is set as the metadata key plan_identifier on the stripe product.
- Combination of price and plan is validated to prevent a user from buying a “higher value” plan with a lower price from another plan
The Billable capability requires the following fields to exist and be filled on the user Entity:
- email: email: The email of the user. Should already be there as it is a default field.
- name: text: The name of the user in stripe.
- country_code: text: ISO 3166-1 alpha-2 country code the user is located in.
- postal_code: text: The postal code of the user.
The fields on the Billable capability can be mapped to re-use existing fields in the options of the capability.
- This is done via the field_mapping option.
  - The key is one of the field identifiers above, and the value is the identifier of the field to use. Custom mapped fields have to exist and be filled! It is best to use "rules": "required" on them
The active_features and active_plans fields on a Buyable Entity are
- statically stored list of “slugs” (the identifiers of all features (unique) from all plans the entity has and the identifiers of all plans of an entity respectively).
- updated when the important events (that also trigger the workflow events) are fired.
  - When the active plans changed
    - i.e. new plan was bought or an existing plan was canceled / deleted
  - When the underlying plan changed
    - i.e. adding or removing features from a plan
- active_features is a list of all “feature flags” that should be enabled for that entity.
  - They are derived from the features of all active plans and are a unique list of comma separated feature identifiers as configured.
(Before deleting a plan (or changing its unique identifier), the bakery planner warns and asks confirmation / needs force.)
When existing plans are DELETED:
- all active subscriptions for that plan are canceled.
- the plan is removed from stripe.
- the plan is removed from all entities.
  - including the active features.

Use Cases

Technical step, by step detailing of common use cases.

Buying a plan

Request to /modules/<module_identifier>/resources/<entity_id>/subscribe/<plan_identifier> with payload:

{
  "redirect_url": "<SPA URL to current entity detail view>/subscription", // e.g. /modules/buyable_thingy/1234/subscription
  "price": "<price_identifier>", // e.g. pro_monthly_usd
  "user_ip": "<known user ip>", // required for stripe tax location validation
  "coupon": "[coupon_identifier]" // optional coupon to apply
}

User (extracted from auth info) will be redirected to stripe checkout page.
- With prefilled email and name as well as required tax info (country and postal code).
When finished, User will be redirected by stripe to SPA (e.g. /modules/buyable_thingy/1234/subscription)
- On success with path params:
  - res=success
- On cancel with path params:
  - res=cancelled
- This will cause the user to be shown the (reloaded) detail view of the entity that was bought.
  - Can be captured by widgets on the detail view to show subscription status by looking at the new values of active_features (or active_plans).

Canceling a subscription, checking active subscriptions, changing payment method etc.

Request to /modules/<module_identifier>/resources/<entity_id>/subscribtion-manager
User will be redirected to stripe customer portal.

If cancelling something, the application will handle this via the webhooks.

Status / Roadmap

TODOs

Figure out what to do with custom values for features. Currently, when a plan update happens, only features defined in the active plans are kept.
- Do we want to keep the custom / unknown feature flag values for features that are not in any defined plan?
  - This would prevent a user from loosing access to a feature that we now no longer sell (i.e. removed from the plan)
  - And it would enable us to use custom feature flags for things that are not in any plan.
    - Which I think is a good idea. But we kindof already have roles for that (i.e. giving access to a feature without buying it)?
